Ksb Pressure Seal Gate Valve

Ksb Pressure Seal Gate Valve

When faced with challenging circumstances, the KSB pressure seal gate valve performs well and demonstrates its real character by offering maximum output and longevity. For the best result, it reduces waste, which boosts profit.


Product Uses?

  • Boiler feed applications
  • Fossil-fuelled power stations
  • Petrochemical industry
  • Pipelines and tank farmst
  • Refineries
  • Process engineering

Ksb Pressure Seal Gate Valve Material

  • WCB
  • WCC
  • WC6
  • WC9
  • C12A

Size

  • 2’’ (50MM) TO 28’’ (700MM)

Brand

  • KSB

Ksb Pressure Seal Pressure Rating

  • 900# Class
  • 1500# Class
  • 2500# Class
  • 3100# Class
  • 3600# Class
Body materials

Overview of available materials

Material Temperature limit
[°C] [°F]
ASTM A216 WCB ≤ 425 ≤ 800
ASTM A216 WCC ≤ 425 ≤ 800
ASTM A217 WC6 ≤ 593 ≤ 1100
ASTM A217 WC9 ≤ 593 ≤ 1100
ASTM A217 C12A ≤ 650 ≤ 1200
Valve Diagram
Gate Valve 150 600 Dimensions
Gate Valve 150 600 Materials
