Item | Sizes | Item Code | End Details |
---|---|---|---|
Cast Iron 'Y' Type Strainer | 15mm TO 50mm | CI-0092 | Screwed Female Ends |
Sr.no | Name Of Parts | No.off | Material | Specification/standard |
---|---|---|---|---|
1. | Body | 1 | C.I. | BSEN 1561 Gr. GJL200 |
2. | Screen | 1 | S.S. | Type 304 1mmø Perforation |
3. | Gasket | 1 | CNAF | - |
4. | Cover | 1 | C.I. | BSEN 1561 Gr. GJL200 |
Nominal Size | 15MM | 20MM | 25MM | 32MM | 40MM | 50MM |
---|---|---|---|---|---|---|
~L±1.6 | 100 | 125 | 145 | 145 | 180 | 200 |
~H | 69 | 70 | 76 | 106.5 | 122 | 162 |
"Rp" | 1/2" | 3/4" | 1″ | 1-1/4" | 1-1/2" | 2" |
Item | Sizes | Test Pressures | Testing Standard | |
---|---|---|---|---|
Body | Seat | |||
Cast Iron 'y' Type Strainer | 15mm to 50mm | 26 Bar (Hyd) | Manufacturer | |
NOTE: 1.The above data is subject to change without notice due to our continual product improvement program,2.Valves Can be supplied in other MOC's on request, Cast Iron (IS 210 Gr. FG 260) Ductile Iron (ASTMA 395 Gr. 60-40-18 / 65-45-15 / GGG 40.30) & D2 (ASTMA 439 Gr. D2/ D2A/ D2B/ D2C) |
